SRT-6200S เครื่องมือวัดความเรียบผิว (Surface Roughness Ra Rz)

฿42,000.00

SRT-6200S เครื่องวัดความเรียบผิว Surface Roughness Tester ตามมาตรฐาน ISO, DIN, ANSI และ JIS สามารถวัดค่าได้ 2 พารามิเตอร์คือ Ra, Rz คุณภาพสูงราคาถูก

  • ย่านวัด Ra : 0.05-10.00 µm
  • ย่านวัด Rz : 0.020-100.0 µm
  • สายวัดแยกออกจากตัวเครื่องใช้งานสะดวก

สอบถามข้อมูลสั่งซื้อ ขอใบเสนอราคา

รหัสสินค้า: SRT-6200S หมวดหมู่:

SRT-6200S เครื่องวัดความเรียบผิว Surface Roughness Tester เป็นเครื่องวัดตามมาตรฐาน ISO, DIN, ANSI และ JIS สามารถวัดค่าได้ 2 พารามิเตอร์คือ Ra, Rz

ย่านการวัด Ra: 0.05-10.00 µm / 1.000-400.0 µinch , Rz: 0.020-100.0 µm / 0.780-4000 µinc

(Option) สามารถส่งข้อมูลการวัดไปยัง PC โดยเชื่อมต่อผ่าน USB / RS-232 สินค้าคุณภาพ ขายราคาถูก จัดส่งทั่วไทย

สำหรับวัดค่า Ra และ Rz

Ra
ค่า Rz Rt

Features SRT-6200

  • Multiple parameter measurement : Ra, Rz
  • Highly sophisticated inductance sensor
  • Four wave filtering methods : RC, PC-RC, GAUSS and D-P
  • Built-In lithium ion rechargeable battery and control circuit with high capacity
    Selectable Metric (µm) and Imperial (µinch)
  • Exclusive DSP processes to output measurement results on LCD
  • Rechargeable battery via USB cable or Power Adapter
SRT-6200S

Specifications SRT-6220

  • Multiple parameter measurement Ra, Rz
  • Filtering methods RC, PC-RC, GAUSS and D-P
  • Measuring Range
  • Ra : 0.05-10.00 µm / 1.000-400.0 µinch
  • Rz : 0.020-100.0 µm / 0.780-4000 µinch
  • Accuracy ≤10%
  • Repeatability ≤ 6%
  • Resolution
  • 0.001µm if reading <10µm
  • 0.01µm if 10µm =reading <100µm
  • 0.1µm if reading =100µm
  • Data output communicate with PC through RS232C interface (optional, not included in set)
  • Store memory 7 groups of measurement
  • Display 4 digits, 10mm LCD with blue backlight
  • Power Li-ion battery, rechargeable
  • Operating conditions
  • Temperature : 0~50°C
  • Humidity : <85%
  • Size 140 x 57 x 48mm
  • Weight about 420g

PDF Catalog
